Lenovo ThinkEdge SE10 Intel Atom® x6425RE 8 GB DDR4-SDRAM 256 GB SSD Mini PC Black

Lenovo ThinkEdge SE10 Intel Atom® x6425RE 8 GB DDR4-SDRAM 256 GB SSD Mini PC Black

  • Brand: Lenovo
  • Category:
  • SKU: 12NH0005GE
  • EAN: 0196804513867
Intel Atom x6425RE (1.5MB Cache, 1.9GHz), 8GB DDR4-SDRAM, 256GB SSD, Intel UHD Graphics, LAN, WLAN, Bluetooth, No OS

Trade Prices

Alternative Suppliers
ECPROF

EU Product - ThinkEdge SE10 ATOM X6425RE 8/256 WiFi6 ohne OS

 12NH0005GE Register free see stock

Related Products

Description

Cost-effective processing power
Rugged, flexible, and cost-effective Edge AI solution for business. From extreme temperatures to the most constrained spaces, ThinkEdge SE10 client users can now scale the spectrums of ruggedness and flexibility thanks to the ground-up design.

Purposefully designed for business
The ThinkEdge SE10 client offers expandable vertical IO capabilities to help businesses scale up or down depending on their needs. With rich temperature coverage, rugged grade component design for 24/7 services. And with its convenient WiFi/Wireless WAN technology, connectivity from Edge to Cloud is a breeze.

Data-ready & secure
Businesses can rely on the security and reliability of the NIST-compliant ThinkShield offered on the SE10 client. With its XClarity in-band manageability and One Platform support, Edge Client and Server devices are secure no matter the challenge.

Specifications may vary depending upon region / model.

Specifications

Processor
Processor cache typeL2
Processor cache1.5 MB
Processor frequency1.9 GHz
Processor modelx6425RE
Number of processors installed1
Processor manufacturerIntel
Processor threads4
Processor cores4
Processor familyIntel Atom®
Memory
Memory layout (slots x size)1 x 8 GB
Internal memory8 GB
Maximum internal memory32 GB
Memory slots2x SO-DIMM
Internal memory typeDDR4-SDRAM
Memory clock speed3200 MHz
Memory channelsDual-channel
Storage
Storage mediaSSD
Number of storage drives installed1
Optical drive typeNo
SSD interfacePCI Express 4.0
SSD capacity256 GB
Number of SSDs installed1
Total storage capacity256 GB
SSD form factorM.2
Total SSDs capacity256 GB
NVMeYes
Graphics
Discrete graphics cardNo
On-board graphics card familyIntel® UHD Graphics
On-board graphics cardYes
Discrete graphics card modelNot available
On-board graphics card modelIntel® UHD Graphics
On-board GPU manufacturerIntel
Optical drive
Optical drive typeNo
Network
Ethernet LANYes
Wi-FiYes
BluetoothYes
Bluetooth version5.1
Wi-Fi standardsWi-Fi 6 (802.11ax)
Ethernet LAN data rates2500 Mbit/s
WLAN controller modelMediaTek MT7921
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Antenna type2x2
WLAN controller manufacturerMediaTek
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
Thunderbolt 3 ports quantity0
HDMI version1.4b
USB 2.0 ports quantity2
Serial ports quantity2
Microphone inYes
Line-outYes
HDMI ports quantity1
Ethernet LAN (RJ-45) ports2
DisplayPorts quantity1
DisplayPort version1.4
Technical details
Product typeMini PC
Trusted Platform Module (TPM)Yes
Product colourBlack
Chassis typeMini PC
Placement supportedHorizontal
Motherboard chipsetIntel SoC
Box contentsIP50 Dust Cover Kits
Compliance certificatesRoHS
Design
VESA mountingYes
Volume0.8 L
Product colourBlack
Chassis typeMini PC
Placement supportedHorizontal
Colour nameBlack (SE10)
Performance
Product typeMini PC
Trusted Platform Module (TPM)Yes
Motherboard chipsetIntel SoC
Trusted Platform Module (TPM) version2.0
Software
Operating system installedNo
Power
Power supply input frequency50/60 Hz
Power supply input voltage100 - 240 V
Power supply65 W
Operational conditions
Operating altitude0 - 3048 m
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%
Operating temperature (T-T)10 - 35 °C
Non-operating altitude0 - 12192 m
Certificates
CertificationErP Lot 6 Low Halogen RoHS compliant REACH TED (ECO-declaration) WEEE Microsoft Azure IoT Edge certified AWS IoT Greengrass certified Ubuntu Core certified Ubuntu Server certified Red Hat Enterprise Linux certified
Low halogenYes
Waste Electrical and Electronic Equipment (WEEE) complianceYes
Compliance certificatesRoHS
Ergonomics
VESA mountingYes
Weight & dimensions
Volume0.8 L
Width179 mm
Depth135 mm
Height34.5 mm
Weight1.5 kg
Packaging content
Mouse includedNo
Display includedNo
Keyboard includedNo
Display
Display includedNo
Certification
Waste Electrical and Electronic Equipment (WEEE) complianceYes
Other features
VESA mountingYes
Trusted Platform Module (TPM)Yes
On-board graphics cardYes
Processor manufacturerIntel
