APC Smart-UPS X, Line Interactive, 2200VA, Rack/tower convertible 4U, 208V-230V, 8x C13+2x C19 IEC, SmartSlot, Extended runtime, Short depth

APC Smart-UPS X, Line Interactive, 2200VA, Rack/tower convertible 4U, 208V-230V, 8x C13+2x C19 IEC, SmartSlot, Extended runtime, Short depth

APC Smart-UPS X, Line Interactive, 2200VA, Rack/tower convertible 4U, 208V-230V, 8x C13+2x C19 IEC, SmartSlot, Extended runtime, Short depth

Trade Prices

Distributor Product SKU Stock Updated Price
EET

Fcory Refurished Smr-Ups

 SMX2200HVR Register free see stock

Related Products

Description

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2200VA line interactive 4U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with IEC 320 C20 input (includes BS1363A, IEC 320 C20 and Schuko CEE 7/EU1-16P power cords), 8x IEC 320 C13 and 2x IEC 320 C19 outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.

Specifications

Power
Output power1980 W
Input operation voltage (min)140 V
Input operation voltage (max)280 V
Output operation voltage (min)208 V
Output operation voltage (max)240 V
Surge energy rating645 J
Efficiency98.1%
Emergency Power Off (EPO)Yes
Output power capacity2.2 kVA
Ports & interfaces
Cable length2 m
USB portYes
SmartSlotYes
AC outlets quantity10 AC outlet(s)
AC outlet typesC13 coupler, C19 coupler
Power plugC20 coupler
Number of output IEC jumpers2
Performance
UPS topologyLine-Interactive
WaveformSine
Auto-restartYes
Automatic Voltage Regulation (AVR)Yes
LED indicatorsYes
Surge protectionYes
Noise level55 dB
Audible alarm(s)Yes
Features
UPS topologyLine-Interactive
WaveformSine
Auto-restartYes
Automatic Voltage Regulation (AVR)Yes
Output power1980 W
Input operation voltage (min)140 V
Input operation voltage (max)280 V
Output operation voltage (min)208 V
Output operation voltage (max)240 V
Surge energy rating645 J
Efficiency98.1%
Surge protectionYes
Emergency Power Off (EPO)Yes
Noise level55 dB
Audible alarm(s)Yes
Output power capacity2.2 kVA
Input frequency50/60 Hz
Battery
Battery life (max)5 year(s)
Battery technologyLead-Acid
Battery recharge time3 h
Hot-swap batteryYes
Cold startYes
Automatic battery testYes
Design
Rack capacity4U
Form factorRackmount/Tower
LED indicatorsYes
Product colourBlack
Cable length2 m
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3048 m
Non-operating altitude0 - 15240 m
Weight & dimensions
Package width586 mm
Package depth633 mm
Package height330 mm
Weight38.6 kg
Width178 mm
Package weight47.7 kg
Height432 mm
Depth483 mm
Packaging data
Package width586 mm
Package depth633 mm
Package height330 mm
Package weight47.7 kg
