Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
AP7541 |
APC-AP7541 | |||
|
RACK PDU BASIC ZERO U 30A 208V View on Xvantage |
2703474 | |||
|
RACK PDU, BASIC, ZERO U, 30A, 200/208V, (20)C13 & (4)C19 |
AP7541 | |||
|
Rack PDU, Basic, Zero U, 30A, 200/208V, (20)C13 & (4)C19 View on InTouch |
2975291 | |||
|
RACK PDU BASIC ZERO U 30A 200/208V ( View on Webshop |
AP7541 | |||
|
Rck PDU sic Zero U 30 |
AP7541 | |||
| Ingram Micro CS |
RACK PDU BASIC ZERO U 30A 208V |
2703474 | |||
|
Basic Rack PDU Zero U - power distribution unit - 4992 VA |
STD10073668 |
| Alternative Suppliers | |||||
|---|---|---|---|---|---|
|
RACK PDU BASIC ZERO U 30A 200/208V ( |
CLAP7541 | |||
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | £417.49 | ||
| Amazon | Used | £279.99 | ||
| Amazon | New | £484.26 | ||
| Amazon | New | £417.48 |
Reasons To Buy
Enables a quick recovery from overload events.
Leveling feet can be quickly adjusted through the use of a screwdriver or drill, eliminating the need to reach underneath with a wrench.
Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures.
Override electronic access with a hard key for power outages and maintenance.
Description
Specifications
| Design | |
|---|---|
| Type | Single-phase |
| PDU types | Basic |
| Mounting | Vertical |
| Product colour | Black |
| Certification | cUL,CSA C22.2 No. 60950-1-03,METI Denan,UL 60950-1,UL |
| Rack capacity | 0U |
| Ports & interfaces | |
| AC outlets quantity | 24 AC outlet(s) |
| AC outlet types | NEMA L6-30P |
| Power plug | NEMA L6-30P |
| Output connections | (20) IEC 320 C13 (4) IEC 320 C19 |
| Input connection type | NEMA L6-30P |
| Features | |
| Cable length | 3 m |
| Certification | cUL,CSA C22.2 No. 60950-1-03,METI Denan,UL 60950-1,UL |
| Ergonomics | |
| Cable length | 3 m |
| Power | |
| Nominal input voltage | 200; 208; 230 V |
| Output voltage | 200 V; 208 V |
| Maximum current | 30 A |
| Maximum total current draw per phase | 24 A |
| Maximum input current per phase | 30 A |
| Load capacity | 4992 VA |
| AC input frequency | 50-60 Hz |
| Certificates | |
| Certification | cUL,CSA C22.2 No. 60950-1-03,METI Denan,UL 60950-1,UL |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Compliance certificates | RoHS, REACH, WEEE |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -25 - 65 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15240 m |
| Weight & dimensions | |
| Weight | 5.57 kg |
| Width | 56 mm |
| Depth | 44 mm |
| Height | 1619 mm |
| Package width | 127 mm |
| Package depth | 152 mm |
| Package height | 2121 mm |
| Package weight | 6.48 kg |
| Packaging content | |
| Cables included | Power |
| Packaging data | |
| Package width | 127 mm |
| Package depth | 152 mm |
| Package height | 2121 mm |
| Package weight | 6.48 kg |
| Technical details | |
| Total carbon footprint (kg of CO2e) | 3936.6696350091 |
| Compliance certificates | RoHS, REACH, WEEE |
| Certification | |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Logistics data | |
| Country of origin | India |
| Customs product code (TARIC) | 8544429090 |
| Total carbon footprint (kg of CO2e) | 3936.6696350091 |
