Tripp Lite N286-40G-PLR4 Cisco-Compatible QSFP+ Transceiver - 40GBase-PLR4, Singlemode MPO/MTP, 1310 nm, 10 km (6.2 mi.)
- Brand: Tripp Lite
- Category:
- SKU: N286-40G-PLR4
- EAN:
Cisco-Compatible QSFP+ Transceiver - 40GBase-PLR4, Singlemode MPO/MTP, 1310 nm, 10 km (6.2 mi.)
Offer details
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | £733.36 |
Related Products
Description
QSFP+ Transceiver Designed for Connection to Your Cisco Network Switch or Server
This QSFP+ transceiver allows you to connect a singlemode fiber optic cable to a 40 Gbps network router, server or switch. It transmits data up to 10 kilometers (6.2 miles) using a 1260 to 1360 nm wavelength. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.
Functionally Equivalent to Cisco QSFP-4X10G-LR-S Transceiver Module
The MSA-compliant N286-40G-PLR4 functions just like the equivalent Cisco QSFP-4X10G-LR-S transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the QSFP-4X10G-LR-S.
Hot-Swappable for Installation Without Network Interruption
This input/output device is fully hot-swappable, so you can install it without a potentially costly network shutdown or device reboot. Just plug the QSFP+ end of the transceiver into your Cisco network device. The other end has an MPO/MTP connector to link with singlemode fiber optic cable (sold separately). A push/pull tab connector is easily accessible in high-density data center applications and makes the plug-and-play transceiver easy to install and remove with one hand.
This QSFP+ transceiver allows you to connect a singlemode fiber optic cable to a 40 Gbps network router, server or switch. It transmits data up to 10 kilometers (6.2 miles) using a 1260 to 1360 nm wavelength. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.
Functionally Equivalent to Cisco QSFP-4X10G-LR-S Transceiver Module
The MSA-compliant N286-40G-PLR4 functions just like the equivalent Cisco QSFP-4X10G-LR-S transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the QSFP-4X10G-LR-S.
Hot-Swappable for Installation Without Network Interruption
This input/output device is fully hot-swappable, so you can install it without a potentially costly network shutdown or device reboot. Just plug the QSFP+ end of the transceiver into your Cisco network device. The other end has an MPO/MTP connector to link with singlemode fiber optic cable (sold separately). A push/pull tab connector is easily accessible in high-density data center applications and makes the plug-and-play transceiver easy to install and remove with one hand.
Specifications
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Fiber optic connector | MTP/MPO |
| Maximum transfer distance | 10000 m |
| Wavelength | 1310 nm |
| Maximum data transfer rate | 40000 Mbit/s |
| Interface type | QSFP+ |
| Single-mode fiber (SMF) supported | Yes |
| SFP transceiver standard | PLR4 |
| Fiber ethernet cabling technology | 40GBASE |
| Country of origin | China |
| Product colour | Silver |
| Housing material | Zinc steel |
| Brand compatibility | Cisco |
| Harmonized System (HS) code | 8517.62.0090 |
| Features | |
| Product colour | Silver |
| Housing material | Zinc steel |
| Brand compatibility | Cisco |
| Country of origin | China |
| Power | |
| Power consumption (typical) | 2 W |
| Certificates | |
| Compliance certificates | CE, REACH, RoHS, UKCA |
| Sustainability | |
| Sustainability compliance | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 85% |
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
| Network | |
| SFP transceiver type | Fiber optic |
| Fiber optic connector | MTP/MPO |
| Maximum data transfer rate | 40000 Mbit/s |
| Interface type | QSFP+ |
| Weight & dimensions | |
| Width | 13.5 mm |
| Depth | 68.1 mm |
| Height | 8.4 mm |
| Weight | 20 g |
| Package depth | 144.8 mm |
| Package width | 78.7 mm |
| Package height | 17.8 mm |
| Package weight | 50 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Package type | Box |
| Technical details | |
| Package width | 78.7 mm |
| Package height | 17.8 mm |
| Maximum transfer distance | 10000 m |
| Wavelength | 1310 nm |
| Sustainability compliance | Yes |
| Master (outer) case GTIN (EAN/UPC) | 10037332279351 |
| Compliance certificates | CE, REACH, RoHS, UKCA |
| Packaging data | |
| Package type | Box |
| Package depth | 144.8 mm |
| Package width | 78.7 mm |
| Package height | 17.8 mm |
| Package weight | 50 g |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Country of origin | China |
| Master (outer) case width | 149.9 mm |
| Master (outer) case length | 185.4 mm |
| Master (outer) case height | 101.6 mm |
| Master (outer) case gross weight | 580 g |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 8517.62.0090 |
| Master (outer) case GTIN (EAN/UPC) | 10037332279351 |
