Tripp Lite N286-40GSR4-MTP Cisco-Compatible QSFP-40G-SR4 QSFP+ Transceiver - 40GBase-SR4, Multimode MTP/MPO, 850 nm, 150 m
- Brand: Tripp Lite
- Category:
- SKU: N286-40GSR4-MTP
- EAN:
Cisco-Compatible QSFP-40G-SR4 QSFP+ Transceiver - 40GBase-SR4, Multimode MTP/MPO, 850 nm, 150 m
Offer details
Related Products
Description
QSFP+ Transceiver Designed for Connection to Your Cisco Network Switch or Server
This QSFP+ transceiver allows you to connect a multimode fiber optic cable to a 40 Gbps network router, server or switch. It transmits data up to 150 meters (492 feet) using an 850 nm wavelength. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.
Functionally Equivalent to Cisco GLC-TE Transceiver Module
The MSA-compliant N286-40GSR4-MTP functions just like the equivalent Cisco QSFP-40G-SR4 transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the QSFP-40G-SR4.
Hot-Swappable for Installation Without Network Interruption
This input/output device is fully hot-swappable, so you can install it without a potentially costly 40 Gbps network shutdown or device reboot. Just plug the QSFP+ end of the transceiver into your Cisco network device. The other end has an MTP/MPO connector to link with multimode fiber cable (sold separately). A push/pull tab connector is easily accessible in high-density data center applications and makes the plug-and-play transceiver easy to install and remove with one hand.
This QSFP+ transceiver allows you to connect a multimode fiber optic cable to a 40 Gbps network router, server or switch. It transmits data up to 150 meters (492 feet) using an 850 nm wavelength. The zinc housing protects against electromagnetic interference (EMI) and excessive power dissipation.
Functionally Equivalent to Cisco GLC-TE Transceiver Module
The MSA-compliant N286-40GSR4-MTP functions just like the equivalent Cisco QSFP-40G-SR4 transceiver module and is manufactured to meet or exceed Cisco specifications. You can use this transceiver with any compatible Cisco router, server or switch and receive the same performance as the QSFP-40G-SR4.
Hot-Swappable for Installation Without Network Interruption
This input/output device is fully hot-swappable, so you can install it without a potentially costly 40 Gbps network shutdown or device reboot. Just plug the QSFP+ end of the transceiver into your Cisco network device. The other end has an MTP/MPO connector to link with multimode fiber cable (sold separately). A push/pull tab connector is easily accessible in high-density data center applications and makes the plug-and-play transceiver easy to install and remove with one hand.
Specifications
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Fiber optic connector | MPO, MTP |
| Maximum transfer distance | 150 m |
| Wavelength | 850 nm |
| Maximum data transfer rate | 40000 Mbit/s |
| Interface type | QSFP+ |
| Single-mode fiber (SMF) supported | No |
| Multi-mode fiber (MMF) supported | Yes |
| SFP transceiver standard | SR4 |
| Country of origin | China |
| Easy to install | Yes |
| Product colour | Silver |
| Hot-swap | Yes |
| Brand compatibility | Cisco |
| Harmonized System (HS) code | 8517.62.0090 |
| Features | |
| Easy to install | Yes |
| Product colour | Silver |
| Hot-swap | Yes |
| Brand compatibility | Cisco |
| Country of origin | China |
| Certificates | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Operating relative humidity (H-H) | 5 - 85% |
| Storage relative humidity (H-H) | 5 - 85% |
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
| Network | |
| SFP transceiver type | Fiber optic |
| Fiber optic connector | MPO, MTP |
| Maximum data transfer rate | 40000 Mbit/s |
| Interface type | QSFP+ |
| Weight & dimensions | |
| Width | 18.3 mm |
| Depth | 116.3 mm |
| Height | 8.4 mm |
| Weight | 60 g |
| Package depth | 78.7 mm |
| Package width | 144.8 mm |
| Package height | 17.8 mm |
| Package weight | 60 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Package width | 144.8 mm |
| Package height | 17.8 mm |
| Hot-swap | Yes |
| Maximum transfer distance | 150 m |
| Wavelength | 850 nm |
| Master (outer) case GTIN (EAN/UPC) | 10037332248623 |
| Compliance certificates | RoHS |
| Packaging data | |
| Package depth | 78.7 mm |
| Package width | 144.8 mm |
| Package height | 17.8 mm |
| Package weight | 60 g |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Country of origin | China |
| Master (outer) case width | 185.4 mm |
| Master (outer) case length | 149.9 mm |
| Master (outer) case height | 101.6 mm |
| Master (outer) case gross weight | 680 g |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 8517.62.0090 |
| Master (outer) case GTIN (EAN/UPC) | 10037332248623 |
