Equip 19"-55" Push-In Pop-Out TV Wall Mount Bracket
- Brand: Equip
- Category:
- SKU: 650325
- EAN: 4015867207956
43"-70" Push-In Pop-Out TV Wall Mount Bracket
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
19"-55" Push-In Pop-Out Tv |
650325 | |||
|
650325 19-70 Push-In Pop-Out TV Wall Mount Bracket. |
650325 | |||
|
43 inch - 70 inch Push - In Pop - Out Wall Mount TV Bracket |
650325 |
| Alternative Suppliers | |||||
|---|---|---|---|---|---|
|
EU Product - Wandhalterung 19-55/1TFT Popout 1Gelenk 50Kg sw lite Retail |
650325 | |||
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | £360.57 |
Related Products
-
Category: Signage Display Mounts -
Category: Signage Display Mounts -
Category: Signage Display Mounts -
Category: Signage Display Mounts
Description
The equip® Push-In Pop-Out TV Mount Bracket is a mounting solution quick to install, and easy to configure. This is a professional mount focusing on single or multiple screen installations, easy and fast installation and simplified maintenance. The Push-In Pop-out feature gives easy-access to any display for quick serviceability, especially at video wall applications. This is one of the major functions needed when building a video wall mounting solution or when integrating a single screen into the wall
Specifications
| Mounting | |
|---|---|
| Minimum screen size | 48.3 cm (19") |
| Maximum weight capacity | 50 kg |
| Number of displays supported | 1 |
| Mounting type | Wall |
| Minimum VESA mount | 100 x 100 mm |
| Maximum VESA mount | 600 x 400 mm |
| Maximum screen size | 139.7 cm (55") |
| Ergonomics | |
| Tilt angle range | 0 - 10° |
| Angle of rotation | 180° |
| Distance to the wall (min) | 11 cm |
| Distance to the wall (max) | 31 cm |
| Cable management | Yes |
| Design | |
| Housing material | Steel |
| Certification | CE |
| Product colour | Black |
| Weight & dimensions | |
| Width | 545 mm |
| Depth | 310 mm |
| Height | 610 mm |
| Weight | 14 kg |
| Depth (max) | 31 cm |
| Package width | 600 mm |
| Package depth | 110 mm |
| Package height | 660 mm |
| Package weight | 15.5 kg |
| Package type | Box |
| Packaging data | |
| Package width | 600 mm |
| Package depth | 110 mm |
| Package height | 660 mm |
| Package weight | 15.5 kg |
| Package type | Box |
| Packaging content | |
| Mounting kit | Yes |
| Manual | Yes |
| Technical details | |
| Angle of rotation | 180° |
| Number of displays supported | 1 |
| Mounting type | Wall |
| Distance to the wall (min) | 11 cm |
| Distance to the wall (max) | 31 cm |
| Compliance certificates | RoHS |
| Certificates | |
| Certification | CE |
| Other features | |
| Country of origin | China |
| Logistics data | |
| Master (outer) case width | 600 mm |
| Master (outer) case length | 110 mm |
| Master (outer) case height | 660 mm |
| Master (outer) case gross weight | 15.5 kg |
| Products per master (outer) case | 1 pc(s) |
| Harmonized System (HS) code | 85299097 |
