Vertiv Liebert GXT5 Double Online Conversion UPS -3000VA/3000W| 230V| With Rackmount Kit | GXT5-3000IRT2UXL

Vertiv Liebert GXT5 Double Online Conversion UPS -3000VA/3000W| 230V| With Rackmount Kit | GXT5-3000IRT2UXL

2U Rack/Tower | 3 Hour Recharge | 3.30 Minute Stand-by | 230 V AC Input | 200 V AC, 208 V AC, 220 V AC Output | 1 x IEC 60320 C19, 6 x IEC 60320 C13 Receptacle(s) | Single Phase | Pure Sine Wave | Serial Port | SNMP/HTTP Remote Monitoring | 5-year Warranty (3-year Standard Warranty + 2-year Extended Warranty)

Trade Prices

Distributor Product SKU Stock Updated Price
Ingram Micro

LIEBERT GXT5 1PH UPS 3KVA IEC

View on Xvantage open_in_new
CI60074 Register free see stock
MB Technology

Liebert GXT5 1ph UPS 3kVA input plug IEC C20 inlet 2U output – 230V output socket groups (6)C13 & (1)C19 rackmount kit 3-year warranty

GXT5-3000IRT2UXL
Fourcom

Liebert GXT5 - UPS - 3000 Watt - 3000

493141
Ingram Micro CS

LIEBERT GXT5 1PH UPS 3KVA IEC

CI60074
Alternative Suppliers
Memory Bank

Liebert GXT5 1ph UPS 3kVA input plug IEC C20 inlet 2U output - 230V output socket groups (6)C13 & (1)C19 rackmount kit 3-year warranty

VUKGXT5-3000IRT2UXL Register free see stock

Description

The Vertiv Liebert GXT5 UPS 3000VA/3000W is a 2U UPS solution for ensuring the health and availability of IT infrastructure. With online, double conversion technology, the UPS protects critical equipment against outages and every type of power disturbance without drawing on battery power, extending battery life and minimizing replacements. This can support a wide range of power environments including 200/208/220/230/240V user configurable AC power and has scalable runtime options with matching external battery cabinets to offer extra time during an outage to support critical equipment and activity. It includes hot-swappable batteries and all hardware for installing it as a tower or in an equipment rack. This single-phase UPS is ENERGY STAR® 2.0 certified and offers leading normal mode power efficiency and Eco-mode for ultimate efficiency levels. It has a three-year factory warranty. It offers premium power protection for critical infrastructure in centralized and edge applications. It comes with a 5-year warranty (3-year factory warranty plus 2-year extended warranty). This promotion is subject to the Distributor’s product availability and is only available while product stocks last. Vertiv reserves the right to provide a 1-month notice to terminate the offer. This offer is not available in conjunction with any other offer/discount.

Specifications

Power
Output voltage regulation±3%
Output power3000 W
Input operation voltage (min)115 V
Input operation voltage (max)288 V
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Efficiency95%
Power factor1
Output power capacity3 kVA
Efficiency (ECO mode)98%
ECO modeYes
Performance
UPS topologyDouble-conversion (Online)
WaveformPure sine
LED indicatorsYes
Surge protectionYes
Noise level48 dB
Features
UPS topologyDouble-conversion (Online)
WaveformPure sine
Output voltage regulation±3%
Output power3000 W
Input operation voltage (min)115 V
Input operation voltage (max)288 V
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Efficiency95%
Surge protectionYes
Power factor1
Noise level48 dB
Output power capacity3 kVA
Efficiency (ECO mode)98%
ECO modeYes
Input frequency40 - 70 Hz
Ports & interfaces
USB portYes
AC outlets quantity7 AC outlet(s)
AC outlet typesC13 coupler, C19 coupler
Power plugC20 coupler
USB 2.0 ports quantity1
Modem (RJ-11) ports1
Ethernet LAN (RJ-45) ports1
USB port typeUSB Type-B
Battery
Battery technologySealed Lead Acid (VRLA)
Typical backup time at half load10.8 min
Typical backup time at full load3.3 min
Hot-swap batteryYes
Design
Rack capacity2U
Form factorRackmount/Tower
LED indicatorsYes
Product colourBlack
SafetyEN 62040-1:2008+A1:2013
Control typeButtons
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Technical details
Sustainability complianceYes
Sustainability certificatesENERGY STAR
Compliance certificatesREACH, RoHS, WEEE
Certificates
Compliance certificatesREACH, RoHS, WEEE
SafetyEN 62040-1:2008+A1:2013
Packaging content
Quick installation guideYes
Cables includedUSB cable
Sustainability
Sustainability complianceYes
Sustainability certificatesENERGY STAR
Safety regulation & standards
SafetyEN 62040-1:2008+A1:2013
Weight & dimensions
Package width717 mm
Package depth570 mm
Package height262 mm
Weight28.5 kg
Width430 mm
Package weight33.4 kg
Height85 mm
Depth540 mm
Packaging data
Quick installation guideYes
Cables includedUSB cable
Package width717 mm
Package depth570 mm
Package height262 mm
Package weight33.4 kg
