Vaddio 999-9630-001 AV conferencing bridge Ethernet LAN Black

Vaddio 999-9630-001 AV conferencing bridge Ethernet LAN Black

2 x HDMI, BNC, USB 3.0 Type B, RJ-45, RS-232, Line In, Line Out, DC, EU/UK

Trade Prices

Distributor Product SKU Stock Updated Price
Videnda Distribution

OneLINK Bridge System for Sony/Panasonic Cameras

999-9630-001 Register free see stock

Description

Makes your camera a conferencing camera: OneLINK Bridge connects a non-USB camera and audio source, and bridges to a USB stream for easy connection to USB-based conferencing applications such as Skype for Business, Google Hangouts, and Zoom. You get traditional videoconferencing audio quality with soft-client connectivity – and without the traditional videoconferencing price tag.
Sounds complicated – but it's not. Tailored for Sony cameras, this OneLINK Bridge kit simplifies installation by extending power, video and control to your camera over a single Cat-5e cable up to 328 ft (100m).

Benefits:
- More flexibility in camera placement
- HDBaseT interface extends power, video and control up to 328 ft (100 m)
- Delivers an uncompressed USB 3.0 media stream for high-definition cloud conferencing
- Connect to any cloud conferencing application, such as Google Hangouts, Skype for Business, WebEx, Zoom and others
- Plug and play usability for BYOD conferencing environments
- Intuitive browser-based user interface for configuration and system administration

Specifications

Video
Supported video modes1080p
Frame rate60 fps
Network
Ethernet LANYes
Design
Product colourBlack
Features
Product colourBlack
Ports & interfaces
HDMI ports quantity2
Audio input2 x Line In
Audio output2 x Line Out
Ethernet LAN (RJ-45) ports4
RS-232 ports2
DC-in jackYes
Power
DC input voltage48 V
Input current1.36 A
Power source typeDC
Packaging content
Cables includedAC, HDMI, LAN (RJ-45), USB
AC adapter includedYes
