Samsung KM24C-P Touchscreen

Samsung KM24C-P Touchscreen

  • Brand: Samsung
  • Category:
  • SKU: CY-KM24CPXEN
  • EAN: 8806095479651
Samsung KM24C-P, 100 - 240 V, 50/60 Hz, 25 W, 0 - 40 °C, 10 - 80 °C, 200 x 200 mm

Trade Prices

Distributor Product SKU Stock Updated Price
Fourcom

KM24C-P - forbindelseskasse

 538907 Register free see stock

Description

Samsung KM24C-P. AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz, Power consumption (typical): 25 W. Panel mounting interface: 200 x 200 mm. Print technology: Thermal transfer, Print speed: 250 mm/sec, Maximum printing width: 8.3 cm. Scanner type: 1D/2D, Linear (1D) barcodes supported: Codabar, Code 128, Code 39 (ASCII), Code 93, EAN-13, EAN-8, GS1 DataBar, Interleaved 2 of 5,.... Width: 334.4 mm, Depth: 236.5 mm, Height: 389.6 mm

Specifications

Display
TouchscreenYes
Network
Ethernet LANYes
Wi-FiNo
BluetoothNo
Ports & interfaces
USB 2.0 ports quantity3
RS-232 ports3
Ethernet LAN (RJ-45) ports1
Power
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Power consumption (typical)25 W
Operational conditions
Storage temperature (T-T)10 - 80 °C
Operating temperature (T-T)0 - 40 °C
Ergonomics
VESA mountingYes
Panel mounting interface200 x 200 mm
Printing
Print technologyThermal transfer
Print speed250 mm/sec
Maximum printing width8.3 cm
Printing media thickness120 µm
Maximum roll diameter8 cm
Built-in barcodesCODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, QR Code, UPC-A, UPC-C
AutocutterYes
Scanning
Scanner type1D/2D
Linear (1D) barcodes supportedCodabar, Code 128, Code 39 (ASCII), Code 93, EAN-13, EAN-8, GS1 DataBar, Interleaved 2 of 5, UPC-A, UPC-E
Weight & dimensions
Width334.4 mm
Depth236.5 mm
Height389.6 mm
Weight7.4 kg
Package width428 mm
Package depth316 mm
Package height471 mm
Package weight9.1 kg
Packaging data
Package width428 mm
Package depth316 mm
Package height471 mm
Package weight9.1 kg
Packaging content
Barcode readerYes
Technical details
Panel mounting interface200 x 200 mm
