Panasonic TH-86CQE2W Signage Display Digital signage flat panel 2.18 m (86") LCD Wi-Fi 400 cd/m² 4K Ultra HD Black
- Brand: Panasonic
- Category:
- SKU: TH-86CQE2W
- EAN: 5025232945290
86" 4K 3840 x 2160, IPS / Edge-LED, 16:9, 1200:1, HDMI, RJ-45, USB, 8 ms, 235W, 220-240V, 50 Hz / 60Hz, 1.9A
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
86" TH-86CQE2W Commercial Display |
PAN86CQE2 | |||
|
86" LED 4k (UHD) 400cd 4x HDMI 1x USB 16/7 Operation Wifi & Media Player |
TH-86CQE2W | |||
|
86" TH-86CQE2W Commercial Display |
PAN86CQE2 |
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | £3,878.84 |
Description
The Panasonic Connect TH-CQE2 Series 4K Professional displays are designed for continuous operation and crystal-clear viewing clarity. The display provides a brightness of 500cd/m² with an anti-glare panel, and minimum haze treatment, reducing the reflection of ambient light and vastly improving visibility. For ultimate flexibility and a clean look without set-top-boxes or cables, the TH-CQE2 Series are also equipped with a built-in TV tuner for access to broadcast, cable, and subscription TV services, making them an ideal solution for corporate, education, and even sports bar applications.
Specifications
| Display | |
|---|---|
| LED backlight | Yes |
| Panel type | IPS |
| Display number of colours | 1.07 billion colours |
| LED backlighting type | Edge-LED |
| Touchscreen | No |
| Active display area (W x H) | 1895 x 1065.9 mm |
| Display technology | LCD |
| Display diagonal | 2.18 m (86") |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 400 cd/m² |
| HD type | 4K Ultra HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 50000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display diagonal (metric) | 217.42 cm |
| Panel life | 50000 h |
| Native aspect ratio | 16:9 |
| Anti-glare screen | Yes |
| Ports & interfaces | |
| USB connector type | USB Type-A, USB Type-C |
| Remote (IR) input | 1 |
| USB port | Yes |
| RS-232C | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated | Yes |
| Ethernet LAN | Yes |
| HDMI ports quantity | 4 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| DVI port | No |
| Audio (L/R) out | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 interface | Yes |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 3 |
| HDMI input ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Audio | |
| Number of built-in speakers | 4 |
| RMS rated power | 24 W |
| Built-in speaker(s) | Yes |
| Bluetooth audio | Yes |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Panel mounting interface | 600 x 400 mm |
| VESA mounting | Yes |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Performance | |
| Purpose | Universal |
| HDCP | Yes |
| HDCP version | 2.2 |
| Wi-Fi | Yes |
| Panel life | 50000 h |
| Power | |
| Power consumption (typical) | 235 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Display width | 1929 mm |
| Display depth | 80 mm |
| Display height | 1116 mm |
| Display weight | 61.7 kg |
| Packaging data | |
| Package width | 2163 mm |
| Package depth | 380 mm |
| Package height | 1405 mm |
| Package weight | 84 kg |
| Remote control included | Yes |
| Cables included | AC |
| Packaging content | |
| Remote control included | Yes |
| Cables included | AC |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Technical details | |
| VESA mounting | Yes |
| USB connector type | USB Type-A, USB Type-C |
| Panel type | IPS |
| LED backlighting type | Edge-LED |
| HDCP 2.2 | Yes |
| Other features | |
| USB connector type | USB Type-A, USB Type-C |
| Panel type | IPS |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Display technology | LCD |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated | Yes |
| Bluetooth version | 5.1 |
| Bluetooth | Yes |
