ICY BOX IB-3740-C31 HDD/SSD enclosure Black 2.5/3.5"
- Brand: ICY BOX
- Category:
- SKU: 60360
- EAN: 4250078168898
SINGLE enclosure for 4x HDD/SSD with USB 3.1 (Gen 2) Type-C® interface and fan
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
USB 3.1 Type-C™ SINGLE enclosure |
573634 |
| Alternative Suppliers | |||||
|---|---|---|---|---|---|
|
EU Product - IB-3740-C31 - Externes 4-fach System f++r 3 5 SATA Festplatten USB 3.1 Gen2 Type-C-? - black |
60360 | |||
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | £195.00 |
Description
It’s the mix
Apart from the improved design, the advantage of the IB-3740-C31 is that it can support 2.5" and 3.5" drives. This makes the device an ideal candidate for users looking for the maximum amount of direct-attached storage space since traditional spinning disks can accommodate a significantly larger amount of data than the largest solid-state drives. If you’re looking to eke out maximum performance, however, you’ll want to use 2.5" SSDs instead.
For the environment
When the host device is not being used or if the data transfer cable is not connected the IB-3740-C31 turns itself into standby mode automatically. In addition, each drive bay has an LED indicator in order to provide information regarding HDD activity (read/write), fan settings, and sync status.
Fast data transfer
The connection between the host PC and the external enclosure is realized by a USB 3.1 Type-C™ port. Thanks to the USB 3.1 (Gen 2) protocol a high data transfer rate of up to 10 Gbit/s can be achieved.
Apart from the improved design, the advantage of the IB-3740-C31 is that it can support 2.5" and 3.5" drives. This makes the device an ideal candidate for users looking for the maximum amount of direct-attached storage space since traditional spinning disks can accommodate a significantly larger amount of data than the largest solid-state drives. If you’re looking to eke out maximum performance, however, you’ll want to use 2.5" SSDs instead.
For the environment
When the host device is not being used or if the data transfer cable is not connected the IB-3740-C31 turns itself into standby mode automatically. In addition, each drive bay has an LED indicator in order to provide information regarding HDD activity (read/write), fan settings, and sync status.
Fast data transfer
The connection between the host PC and the external enclosure is realized by a USB 3.1 Type-C™ port. Thanks to the USB 3.1 (Gen 2) protocol a high data transfer rate of up to 10 Gbit/s can be achieved.
Specifications
| Storage | |
|---|---|
| Number of storage drives supported | 4 |
| Storage drive size | 2.5/3.5" |
| Supported storage drive interfaces | Serial ATA, Serial ATA II, Serial ATA III |
| Maximum storage capacity | 10 TB |
| RAID levels | JBOD |
| Ports & interfaces | |
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
| USB connectivity | Yes |
| USB connector type | USB Type-C |
| USB connector gender | Female |
| USB ports quantity | 1 |
| DC-in jack | Yes |
| Technical details | |
| RAID levels | JBOD |
| Plug and Play | Yes |
| Number of fans | 1 fan(s) |
| Material | Aluminium, Plastic |
| LED indicators | Yes |
| Fan diameter | 8 cm |
| Data transfer rate | 10 Gbit/s |
| Product colour | Black |
| Chipset | VIALabs VL820, VL715 |
| Cable length | 1 m |
| USB version | 3.2 Gen 2 (3.1 Gen 2) |
| Country of origin | Taiwan |
| Maximum storage capacity | 10 TB |
| Harmonized System (HS) code | 84718000 |
| Design | |
| Product type | HDD/SSD enclosure |
| On/off switch | Yes |
| Number of fans | 1 fan(s) |
| Material | Aluminium, Plastic |
| LED indicators | Yes |
| Fan diameter | 8 cm |
| Product colour | Black |
| Cable length | 1 m |
| Performance | |
| UASP support | Yes |
| Country of origin | Taiwan |
| Plug and Play | Yes |
| Data transfer rate | 10 Gbit/s |
| Chipset | VIALabs VL820, VL715 |
| Power | |
| Power source type | DC |
| AC adapter output voltage | 12 V |
| AC adapter output current | 5 A |
| AC adapter input voltage | 100 - 240 V |
| AC adapter input current | 1.6 A |
| AC adapter frequency | 50 - 60 Hz |
| Power consumption (max) | 60 W |
| Packaging data | |
| Package weight | 3.43 kg |
| Package width | 295 mm |
| Package depth | 160 mm |
| Package height | 270 mm |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Mac compatibility | Yes |
| Weight & dimensions | |
| Weight | 2.13 kg |
| Width | 225 mm |
| Depth | 127 mm |
| Height | 170 mm |
| Package weight | 3.43 kg |
| Cable length | 1 m |
| Package width | 295 mm |
| Package depth | 160 mm |
| Package height | 270 mm |
| Packaging content | |
| Screws included | Yes |
| Manual | Yes |
| Screwdriver included | Yes |
| Cables included | USB Type-C |
| Logistics data | |
| Master (outer) case width | 606 mm |
| Master (outer) case length | 503 mm |
| Master (outer) case height | 290 mm |
| Master (outer) case gross weight | 20.6 kg |
| Products per master (outer) case | 6 pc(s) |
| Harmonized System (HS) code | 84718000 |
