HPE SN6000C 8Gb 16-port

  • Brand: HPE
  • Category:
  • SKU: AW585A
  • EAN: 4948382711717 8849628227534 08 ...8227534 0884962822753 0882658325748 4054317999614more
HP SN6000C 8Gb 16-port Fibre Channel Switch

Trade Prices

Distributor Product SKU Stock Updated Price
TD Synnex UK

HP StorageWorks SN6000C 8Gb 16-port Fibre Channel Switch

View on InTouch open_in_new 		2025475 Register free see stock

Retail Prices

Merchant Product Condition Updated Price
Amazon Used £324.65

Related Products

Description

The HP StorageWorks SN6000C Fibre Channel Switch is a high-performance, flexible, cost-effective platform providing high-density, 8 Gbps ports for storage networking deployments in small, medium-sized, and large enterprise environments. The SN6000C offers outstanding value by providing high-availability, security, and ease of use at a cost-effective price in a compact one-rack-unit (1RU) form factor. With the flexibility to expand from 16 to 48 ports in 8-port increments, the SN6000C offers the densities required to scale from an entry-level departmental switch to top-of-the-rack switch to edge connectivity in enterprise SANs. The SN6000C delivers a non-blocking architecture, with all 48 1/2/4/8-Gbps ports operating at line rate concurrently.; The SN6000C is powered by NX-OS Software and is compatible with C-series 9500 Series Multilayer Directors and C-series MDS 9100 and 9200 Series Multilayer Fabric Switches, providing transparent, end-to-end service in core-edge deployments.

High Performance with Exceptional Flexibility

• With 8 Gbps of dedicated bandwidth for each port and aggregate platform bandwidth of 384 Gbps, the HP StorageWorks SN6000C Fibre Channel Switch is designed to meet the performance and scalability requirements of the most demanding environments.


Intelligent Storage Networking Services at a Cost-effective Price

• Supports innovative features such as VSANs, PortChannels, quality of service (QoS), SAN security, SAN management, hardware-enforced zoning, and In Service Software Upgrade (ISSU) at no additional cost to the user.


High Availability Platform

• The HP SN6000C FC Switch is designed for mission-critical environments in which downtime is unacceptable.


Simplified Management

• Supports SAN plug-and-play capability as well as built-in storage network management, with all features available through a command-line interface (CLI) or the C-series Fabric Manager for simplified storage management.

Specifications

Management features
System event logYes
Quality of Service (QoS) supportYes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity16
Fiber ports quantity16
Network
Broadcast storm controlYes
Data transmission
Supported data transfer rates1/2/4Gbit/s
Maximum data transfer rate8 Gbit/s
Security
Static port securityYes
SSH/SSL supportYes
Security algorithms256-bit AES, SSH, SSL/TLS
Access Control List (ACL)Yes
Protocols
Management protocolsSNMPv3
Supported network protocolsFibre Channel
Design
LED indicatorsYes
CertificationUL, CAN/CSA, EN, IEC, AS/NZS, FCC, ICES, CISPR22, VCC, KN24, NEBS, ETSI
Power
Input voltage100 - 240 V
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Other features
Dimensions (WxDxH)571.5 x 679.5 x 215.9 mm
Connectivity technologyWired
Wi-FiNo
Power supply300 W
Networking featuresGigabit Ethernet
Input frequency50/60 Hz
Input voltage100 - 240 V
Operational conditions
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)5 - 95%
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90%
Operating altitude-60 - 2000 m
Weight & dimensions
Weight12.8 kg
Certificates
CertificationUL, CAN/CSA, EN, IEC, AS/NZS, FCC, ICES, CISPR22, VCC, KN24, NEBS, ETSI
Indication
LED indicatorsYes
