A 10-Gigabit transceiver in SFP+ form-factor that supports the 10-Gigabit SR standard, providing 10-Gigabit connectivity up to 400m on OM4 multi-mode fiber.

What's new
- SFP+ form factor
- 10G Ethernet transmission speed
- 400m transmissions on OM4 multi-mode cable
- 300m transmissions on OM3 multi-mode cable
- 850nm wavelength

Features
10Gb Ethernet transmission rate with SFP+ form factor

Transmissions are up to 300m on MMF (SR), up to 220 m MMF (LRM) and 10 km on SMF (LR)

Low power consumption at <0.8W for SR, <1W for LRM and LR

Duplex LC connector

Cable type
62.5/125 ?m or 50/125 ?m (core/cladding) diameter, graded-index, low metal content, multimode fiber optic, complying with ITU-T G.651 and ISO/IEC793-2Type A1b or A1a, respectively

Maximum distance
2-26m with 62.5 ?m multimode cable @ 160 MHz*km 2-33m with 62.5 ?m multimode cable @ 200 MHz*km 2-66m with 50 ?m multimode cable @ 400 MHz*km 2-82m with 50 ?m multimode cable @ 500 MHz*km 2-300m with 50 ?m multimode cable @ 2000 MHz*km

Fiber type
Multi Mode

Product differentiator
A 10-Gigabit transceiver in SFP+ form-factor that supports the 10-Gigabit SR standard, providing 10-Gigabit connectivity up to 300 m on multimode fiber.
