Fujitsu ESPRIMO D738/E94+ Intel® Core™ i5 i5-9400 8 GB DDR4-SDRAM 256 GB SSD Windows 10 Pro SFF PC Black
- Brand: Fujitsu
- Category:
- SKU: VFY:D0738P15AMGB
- EAN: 4065221301660
Intel Core i5-9400 (9MB Cache, 2.9GHz), 8GB DDR4-SDRAM, 256GB SSD, Intel UHD Graphics 630, LAN, Windows 10 Pro 64-bit
Offer details
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | £600.93 |
Description
Small form factor PC in a more compact and space-saving design
The new FUJITSU ESPRIMO D738 Desktop PC provides advanced expandability features in a smaller housing. With up to 9th Gen Intel® Core™ processors, a switched monitor outlet and a power supply with 94% efficiency ensure best energy efficiency coupled with high performance. To meet the system upgrade requirements, it offers high flexibility with space for up to three mass storage drives. Optional Intel® Standard Manageability helps keep administration and rollout costs low. Optional security functions, such as the integrated cabinet lock, EraseDisk and SmartCard reader help secure your valuable business data and hardware components.
Ultimate usability
Benefit from a wide range of features which ease your workaday life
ON/OFF switch, I/Os in front for easy access control and use of the system (audio, USB Type C, optional SD card reader, SmartCard reader and ODD)
Quiet system
Pleasant working environment due to an extremely quiet system
Innovative hardware design with optimized cooling concept ensures silent operations
Always Available Office PC - stay connected and save power
Be ready for instant communication and a significantly reduced energy bill
Innovative Low Power Active Mode and energy-efficient integrated power supply
Advanced system management
Simple system administration for complex IT infrastructures
Intel® Standard manageability technology (ISM) optional and DeskView manageability suite
Low carbon footprint
Another example of Fujitsu’s commitment to environmental protection and sustainability
Low power active function and energy-efficient power supply; less cables due to onboard LED/on/off switch, USB and audio connectors; less raw material used in printed circuit board (PCB) -reduction of up to 20% in PCB when compared to a 10 liter system
The new FUJITSU ESPRIMO D738 Desktop PC provides advanced expandability features in a smaller housing. With up to 9th Gen Intel® Core™ processors, a switched monitor outlet and a power supply with 94% efficiency ensure best energy efficiency coupled with high performance. To meet the system upgrade requirements, it offers high flexibility with space for up to three mass storage drives. Optional Intel® Standard Manageability helps keep administration and rollout costs low. Optional security functions, such as the integrated cabinet lock, EraseDisk and SmartCard reader help secure your valuable business data and hardware components.
Ultimate usability
Benefit from a wide range of features which ease your workaday life
ON/OFF switch, I/Os in front for easy access control and use of the system (audio, USB Type C, optional SD card reader, SmartCard reader and ODD)
Quiet system
Pleasant working environment due to an extremely quiet system
Innovative hardware design with optimized cooling concept ensures silent operations
Always Available Office PC - stay connected and save power
Be ready for instant communication and a significantly reduced energy bill
Innovative Low Power Active Mode and energy-efficient integrated power supply
Advanced system management
Simple system administration for complex IT infrastructures
Intel® Standard manageability technology (ISM) optional and DeskView manageability suite
Low carbon footprint
Another example of Fujitsu’s commitment to environmental protection and sustainability
Low power active function and energy-efficient power supply; less cables due to onboard LED/on/off switch, USB and audio connectors; less raw material used in printed circuit board (PCB) -reduction of up to 20% in PCB when compared to a 10 liter system
Specifications
| Processor | |
|---|---|
| Processor generation | 9th gen Intel® Core™ i5 |
| Processor operating modes | 64-bit |
| Processor lithography | 14 nm |
| Processor codename | Coffee Lake |
| Bus type | DMI3 |
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Tjunction | 100 °C |
| Thermal Design Power (TDP) | 65 W |
| PCI Express configurations | 1x8+2x4, 1x16, 2x8 |
| Maximum number of PCI Express lanes | 16 |
| Memory bandwidth supported by processor (max) | 41.6 GB/s |
| Processor cache type | Smart Cache |
| Processor cache | 9 MB |
| Processor frequency | 2.9 GHz |
| Processor model | i5-9400 |
| Number of processors installed | 1 |
| Processor manufacturer | Intel |
| Processor boost frequency | 4.1 GHz |
| System bus rate | 8 GT/s |
| Processor socket | LGA 1151 (Socket H4) |
| Processor threads | 6 |
| Processor cores | 6 |
| PCI Express slots version | 3.0 |
| Processor family | Intel® Core™ i5 |
| Memory | |
| Internal memory | 8 GB |
| Maximum internal memory | 64 GB |
| Memory slots | 4x DIMM |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2666 MHz |
| Storage | |
| Storage media | SSD |
| Optical drive type | DVD Super Multi |
| SSD capacity | 256 GB |
| Number of SSDs installed | 1 |
| Card reader integrated | Yes |
| Total storage capacity | 256 GB |
| SSD form factor | M.2 |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card dynamic frequency (max) | 1050 MHz |
| On-board graphics card base frequency | 350 MHz |
| Maximum on-board graphics card memory | 64 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card ID | 0X3E98/x92 |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics 630 |
| On-board GPU manufacturer | Intel |
| Optical drive | |
| Optical drive type | DVD Super Multi |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB 2.0 ports quantity | 4 |
| PS/2 ports quantity | 2 |
| Microphone in | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | Yes |
| DisplayPorts quantity | 2 |
| DC-in jack | Yes |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| Technical details | |
| Intel 64 | Yes |
| Cable lock slot type | Kensington |
| Product type | PC |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Product colour | Black |
| Chassis type | SFF |
| Audio system | High Definition Audio |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Yes |
| Audio output channels | 5.1 channels |
| Motherboard chipset | Intel Q370 |
| Compliance certificates | RoHS |
| Design | |
| Volume | 8 L |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Chassis type | SFF |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Yes |
| Intel® vPro™ Platform Eligibility | No |
| Performance | |
| Embedded options available | No |
| Audio chip | Realtek ALC671 |
| Password protection | Yes |
| Password protection type | BIOS, Supervisor, User |
| Product type | PC |
| Audio system | High Definition Audio |
| Audio output channels | 5.1 channels |
| Motherboard chipset | Intel Q370 |
| Harmonized System (HS) code | 84715000 |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Pro |
| Processor special features | |
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® OS Guard | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | No |
| Intel Trusted Execution Technology | No |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel® Secure Key | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel Clear Video Technology | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Yes |
| Thermal solution specification | PCG 2015C |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Scalability | 1S |
| Processor package size | 37.5 x 37.5 mm |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 0.00 |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Identity Protection Technology version | 1.00 |
| Processor ARK ID | 134898 |
| Intel 64 | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® vPro™ Platform Eligibility | No |
| Power | |
| Power supply input frequency | 50 - 60 Hz |
| Power supply input voltage | 100 - 240 V |
| Power supply | 280 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 85% |
| Operating temperature (T-T) | 10 - 35 °C |
| Certificates | |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Volume | 8 L |
| Width | 313 mm |
| Depth | 286 mm |
| Height | 89 mm |
| Weight | 5 kg |
| Packaging content | |
| Display included | No |
| Logistics data | |
| Harmonized System (HS) code | 84715000 |
| Other features | |
| On-board graphics card | Yes |
| Processor manufacturer | Intel |
| Harmonized System (HS) code | 84715000 |
