| Projector |
|---|
| Number of colours | 1.073 billion colours |
| White light output | 3200 ANSI lumens |
| Colour light output | 3200 ANSI lumens |
| Projector native resolution | WXGA (1280x768) |
| Native aspect ratio | 4:3 |
| Supported aspect ratios | 4:3 |
| Screen size compatibility | 1270 - 2743.2 mm (50 - 108") |
| Projection distance | 0.5 - 1.3 m |
| Contrast ratio (typical) | 16000:1 |
| Zoom ratio | 1.35:1 |
| Vertical scan range | 50 - 85 Hz |
| Projector brightness (economic mode) | 1800 ANSI lumens |
| Matrix type | 3-panel (p-Si TFT active) |
| Matrix size | 1.4 cm (0.55") |
| Keystone correction, vertical | 15° |
| Keystone correction, horizontal | 15° |
| Projection technology | 3LCD |
| Projector brightness | 3200 ANSI lumens |
| Lamps |
|---|
| Lamp power | 215 W |
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 10000 h |
| Light source |
|---|
| Lamp power | 215 W |
| Light source type | Lamp |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 10000 h |
| Lens system |
|---|
| Zoom ratio | 1.35:1 |
| Focus | Manual |
| Focal length range | 0 - 6.4 mm |
| Throw ratio | 0.55:1 |
| Scanning frequency |
|---|
| Vertical scan range | 50 - 85 Hz |
| Video |
|---|
| Video processing | 10 bit |
| Full HD | No |
| 3D | No |
| Audio |
|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 16 W |
| Ports & interfaces |
|---|
| DC-in jack | Yes |
| VGA (D-Sub) ports quantity | 3 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 0 |
| USB 2.0 ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| Composite video in | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| Headphone outputs | 2 |
| Microphone in | Yes |
| S-Video inputs quantity | 1 |
| Serial interface type | RS-232 |
| RS-232 ports | 1 |
| DVI port | No |
| Component video (YPbPr/YCbCr) in | 2 |
| Network |
|---|
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN (RJ-45) ports | 0 |
| Sound emission |
|---|
| Noise level | 37 dB |
| Noise level (economic mode) | 29 dB |
| Technical details |
|---|
| DC-in jack | Yes |
| Product colour | White |
| Lamp power | 215 W |
| Products per pallet | 40 pc(s) |
| Quantity per pack | 1 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 2.25 m |
| Products per pallet layer (UK) | 6 pc(s) |
| Products per pallet layer | 4 pc(s) |
| Products per pallet (UK) | 60 pc(s) |
| Pallet width (UK) | 100 cm |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 2.25 m |
| Performance |
|---|
| Vertical scan range | 50 - 85 Hz |
| Noise level | 37 dB |
| Noise level (economic mode) | 29 dB |
| Features |
|---|
| Noise level | 37 dB |
| Noise level (economic mode) | 29 dB |
| Country of origin | China |
| Multimedia |
|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 16 W |
| Design |
|---|
| Product type | Short throw projector |
| Cable lock slot type | Kensington |
| Product colour | White |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Placement | Desktop, Ceiling |
| Power |
|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power source | AC |
| Power consumption (typical) | 298 W |
| Power consumption (standby) | 0.28 W |
| Power consumption (PowerSave) | 221 W |
| Packaging data |
|---|
| Package width | 385 mm |
| Package depth | 490 mm |
| Package height | 210 mm |
| Package weight | 5.86 kg |
| Security |
|---|
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Indication |
|---|
| LED indicators | Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -10 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 35 °C |
| Weight & dimensions |
|---|
| Package width | 385 mm |
| Package depth | 490 mm |
| Package height | 210 mm |
| Weight | 3.7 kg |
| Width | 344 mm |
| Depth | 315 mm |
| Height | 94 mm |
| Package weight | 5.86 kg |
| Packaging content |
|---|
| Remote control included | Yes |
| Batteries included | Yes |
| Logistics data |
|---|
| Products per pallet | 40 pc(s) |
| Quantity per pack | 1 pc(s) |
| Pallet gross width | 80 cm |
| Pallet gross length | 120 cm |
| Pallet gross height | 2.25 m |
| Products per pallet layer (UK) | 6 pc(s) |
| Products per pallet layer | 4 pc(s) |
| Products per pallet (UK) | 60 pc(s) |
| Pallet width (UK) | 100 cm |
| Pallet length (UK) | 120 cm |
| Pallet height (UK) | 2.25 m |
| Other features |
|---|
| RS-232 ports | 1 |
