EnGenius Cloud Managed AP Indoor Dual Band 11ax 1148+2400Mbps 4T4R 2.5GbE PoE.at(+) 3dBi ia
- Brand: EnGenius
- Category:
- SKU: ECW230
- EAN: 0655216009615 4713361934940
2.4 GHz + 5 GHz, IEEE 802.11ax, 802.11a/b/g/n/ac, MU-MIMO, 205 x 205 x 41.5 mm, 597 g
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Managed Indoor 11ax 4x4 Access point - Ceiling mount |
ECW230 |
Description
EnGenius Cloud Managed Wi-Fi 6 4×4 Indoor Access Point ECW230 supports dual concurrent 802.11ax Wi-Fi 6 architecture, delivering supercharged speeds up to 2,400 Mbps (5 GHz), and up to 1,200 Mbps (2.4 GHz). With WPA3 & WPA2-AES authentication support, remote monitoring & troubleshooting, and Mesh Wireless Support for optimized signal quality, it's easy to set up and manage an unlimited number of APs with the EnGenius Cloud App.
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 2400 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Transmitting power | 23 dBmW |
| Reset button | Yes |
| Spread spectrum method | OFDMA, DSSS, OFDM |
| Frequency band | 2.4 - 2.482, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 2400 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Wireless LAN features | |
| Frequency band | 2.4 - 2.482, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
| Network | |
| Spread spectrum method | OFDMA, DSSS, OFDM |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u |
| Security | |
| Cable lock slot | Yes |
| Number of SSID supported | 8 |
| Security algorithms | WPA3, 64-bit WEP, 128-bit WEP, 152-bit WEP, SSH, WPA, WPA-TKIP, WPA2, WPA2-AES, WPA2-PSK |
| MAC address filtering | Yes |
| Service Set Identifier (SSID) features | Multiple SSIDs |
| Management features | |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Features | |
| 6 GHz | No |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Transmitting power | 23 dBmW |
| Spread spectrum method | OFDMA, DSSS, OFDM |
| Frequency band | 2.4 - 2.482, 5.15 - 5.25, 5.25 - 5.35, 5.47 - 5.725, 5.725 - 5.85 GHz |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 2400 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Maximum data transfer rate (2.4 GHz) | 1148 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
| Fit AP mode features | Mesh networking |
| Virtual LAN features | Tagged VLAN |
| Protocols | |
| Management protocols | SNMP |
| Ports & interfaces | |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Power | |
| Power consumption (max) | 19.5 W |
| Power over Ethernet (PoE) | Yes |
| Design | |
| Placement | Ceiling, Wall |
| Product colour | White |
| Reset button | Yes |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Antenna | |
| Antenna type | Internal |
| Antennas quantity | 8 |
| Antenna gain level (max) | 3 dBi |
| Antenna direction type | Omni-directional |
| Antenna features | Integrated antenna |
| Technical details | |
| Transmitting power | 23 dBmW |
| Reset button | Yes |
| Harmonized System (HS) code | 85176990 |
| Indication | |
| LED indicators | Yes |
| Weight & dimensions | |
| Width | 210 mm |
| Depth | 210 mm |
| Weight | 597 g |
| Height | 33.2 mm |
| Package width | 245 mm |
| Package depth | 85 mm |
| Package height | 245 mm |
| Package weight | 911 g |
| Packaging data | |
| Quick start guide | Yes |
| Package width | 245 mm |
| Package depth | 85 mm |
| Package height | 245 mm |
| Package weight | 911 g |
| Packaging content | |
| Quick start guide | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 80 °C |
| Logistics data | |
| Master (outer) case width | 460 mm |
| Master (outer) case length | 520 mm |
| Master (outer) case height | 270 mm |
| Master (outer) case gross weight | 11.9 kg |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 85176990 |
