Digitus SOHO Pro network set, 254 mm (10") - 6U, 315 x 300 mm (W x D)
- Brand: Digitus
- Category:
- SKU: DN-49101-SET
- EAN: 4016032499466
10" network bundle, 6U cabinet and equipment, bl SOHO Pro version, unmounted
Offer details
Related Products
Description
Complete set for setting up a compact 254 mm (10") network, incl. cabinet, shelf, socket strip, switch, patch panel, keystone modules, patch cables
- Maximum design freedom: thanks to unassembled delivery, all 10" components can be individually positioned.
- Including wall-mounted enclosure SOHO PRO, 6U, 325 x 315 x 300 mm, unassembled (DN-49101)
- Including shelf, 1U (DN-10-TRAY-2-B)
- Including socket strip, 1U, 4 x earthing contact (DN-95418)
- Including Gigabit Ethernet switch, 8-port (DN-80114)
- Including modular patch panel, 12-port (DN-91420)
- Including 12 x Keystone module, CAT 6A, shielded (DN-93615)
- Including 10 x patch cable, CAT 6A, S/FTP, 0.25 m
Whether in the home, office or in sub-distribution boards with limited space: With the compact 254 mm (10") solutions from the SOHO Pro series, you can install your network wherever you want. Installation takes just a few steps and is child's play thanks to the enclosed step-by-step instructions. Available in three versions of height units (6U, 9U, 12U), these network sets include perfectly matched DIGITUS components to ensure quick and easy IT cabling ready for use. The network cabinet and the respective accessories (e.g. switch, patch panel, socket strip, shelf, cable management panel, patch cable, etc.) are supplied in a compact cardboard box.
- Maximum design freedom: thanks to unassembled delivery, all 10" components can be individually positioned.
- Including wall-mounted enclosure SOHO PRO, 6U, 325 x 315 x 300 mm, unassembled (DN-49101)
- Including shelf, 1U (DN-10-TRAY-2-B)
- Including socket strip, 1U, 4 x earthing contact (DN-95418)
- Including Gigabit Ethernet switch, 8-port (DN-80114)
- Including modular patch panel, 12-port (DN-91420)
- Including 12 x Keystone module, CAT 6A, shielded (DN-93615)
- Including 10 x patch cable, CAT 6A, S/FTP, 0.25 m
Whether in the home, office or in sub-distribution boards with limited space: With the compact 254 mm (10") solutions from the SOHO Pro series, you can install your network wherever you want. Installation takes just a few steps and is child's play thanks to the enclosed step-by-step instructions. Available in three versions of height units (6U, 9U, 12U), these network sets include perfectly matched DIGITUS components to ensure quick and easy IT cabling ready for use. The network cabinet and the respective accessories (e.g. switch, patch panel, socket strip, shelf, cable management panel, patch cable, etc.) are supplied in a compact cardboard box.
Specifications
| Features | |
|---|---|
| Size (imperial) | 25.4 cm (10") |
| Key lock | Yes |
| Frame type | Closed |
| Rack capacity | 6U |
| International Protection (IP) code | IP20 |
| Adjustable mounting rails | Yes |
| Back door construction | Steel |
| Front door construction | Glass |
| Side panel construction | Steel |
| Cable management | Yes |
| Front door key lock | Yes |
| Type | Wall mounted rack |
| Maximum weight capacity | 60 kg |
| Material | Steel |
| Cooling type | Passive |
| Product colour | Black |
| Rack rails | Yes |
| Adjustable depth | Yes |
| Door opening angle | 200° |
| Side panel style | Blind |
| Front door style | Glass door |
| Back door style | Blind |
| Weight & dimensions | |
| Package depth | 400 mm |
| Package width | 370 mm |
| Package height | 370 mm |
| Package weight | 9.42 kg |
| Width | 315 mm |
| Depth | 300 mm |
| Height | 325 mm |
| Weight | 7.52 kg |
| Size (imperial) | 25.4 cm (10") |
| Maximum weight capacity | 60 kg |
| Packaging content | |
| Quick installation guide | Yes |
| Packaging data | |
| Quick installation guide | Yes |
| Package depth | 400 mm |
| Package width | 370 mm |
| Package height | 370 mm |
| Package weight | 9.42 kg |
| Technical details | |
| Package width | 370 mm |
| Package height | 370 mm |
| Type | Wall mounted rack |
| Size (imperial) | 25.4 cm (10") |
| Cooling type | Passive |
| Rack capacity | 6U |
| International Protection (IP) code | IP20 |
| Colour | |
| Product colour | Black |
| Material | |
| Material | Steel |
