Conen Mounts Motorized monitor wall mount, 50 cm of vertical travel
- Brand: Conen Mounts
- Category:
- SKU: SCETAWLB
- EAN:
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Clevertouch motorised height adjustable wall lift L/A up to 86 SCETAWLBK |
1542805 |
Reasons To Buy
Four leveling feet
These four leveling feet allow you to level out any unevenness in the floor so that the monitor wall mount can transfer the weight of the monitor over the column to the floor. For this purpose, the individual ground leveling foot can be turned in or out.
Quick snap lock
With the new innovative quick snap locks the monitors can simply be hung in place on the monitor wall mount. This makes the assembly easy and fast. In addition, the monitor can be secured against theft with a standard pad lock.
Remote control of height adjustment
The electrically height-adjustable display & monitor stands come standard with a wired remote control. With two buttons, the display stand can gently be raised and lowered. Controlled movements protect the sensitive touch screen displays.
2.76 inch Z-brackets
By default, we supply wall mounting brackets with each display wall mount. This wall mounting set consists of two galvanized Z-shaped brackets, which allow a wall clearance of 2.76 inch (7 cm). Further wall mounting solutions are available as accessories.
Display mount for 42" to 100" displays
This frame accommodates 42 to 100 inch monitors. The sturdy construction consists of 2 mm powder coated steel. Power strips can be mounted on the frame and, thanks to the cable management, no cables hang down on the system.
Description
The SCETAWLB is designed for flat panel displays up to 100”. The units feature a sturdy display mount with integrated cable management and "pull & release" locking brackets for quick and easy mounting of the display.
The SCETAWLB monitor wall mount comes with a column that offers 50 cm / 20" of vertical travel.
The unit comes flat-packed in 2 cartons and is courier-shippable.
Specifications
| Mounting | |
|---|---|
| Minimum screen size | 106.7 cm (42") |
| Maximum weight capacity | 136 kg |
| Number of displays supported | 1 |
| Mounting type | Wall |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 800 x 600 mm |
| Maximum screen size | 2.54 m (100") |
| Ergonomics | |
| Height adjustment | Yes |
| Height adjustment range | 1315 - 1815 mm |
| Telescopic | Yes |
| Minimum distance to floor | 99.5 cm |
| Maximum distance to floor | 149.5 cm |
| Distance to the wall (max) | 7 cm |
| Remotely operated | Yes |
| Design | |
| Housing material | Aluminium |
| Product colour | Black |
| Power | |
| Remotely operated | Yes |
| Weight & dimensions | |
| Width | 890 mm |
| Depth | 165 mm |
| Height | 1790 mm |
| Weight | 28.7 kg |
| Package 2 weight | 13.6 kg |
| Package 2 dimensions (W x D x H) | 900 x 450 x 160 mm |
| Package width | 970 mm |
| Package depth | 270 mm |
| Package height | 220 mm |
| Package weight | 19.5 kg |
| Packaging data | |
| Package 2 weight | 13.6 kg |
| Package 2 dimensions (W x D x H) | 900 x 450 x 160 mm |
| Package width | 970 mm |
| Package depth | 270 mm |
| Package height | 220 mm |
| Package weight | 19.5 kg |
| Package 1 weight | 19.5 kg |
| Package 1 dimensions (WxDxH) | 970 x 220 x 270 mm |
| Technical details | |
| Telescopic | Yes |
| Remotely operated | Yes |
| Number of displays supported | 1 |
| Mounting type | Wall |
| Minimum distance to floor | 99.5 cm |
| Maximum distance to floor | 149.5 cm |
| Distance to the wall (max) | 7 cm |
| Logistics data | |
| Harmonized System (HS) code | 85299097 |
