Conen Mounts Motorized heavy duty XL flat screen tv & monitor cart with 70 cm of vertical travel
- Brand: Conen Mounts
- Category:
- SKU: SCETAD3535B
- EAN:
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Mounts Motorized heavy duty XL flat screen tv mount |
SCETAD3535B |
Related Products
Reasons To Buy
Quick snap lock
With the new innovative quick snap locks the monitors can simply be hung in place on the monitor wall mount. This makes the assembly easy and fast. In addition, the monitor can be secured against theft with a standard pad lock.
Remote control of height adjustment
The electrically height-adjustable display & monitor stands come standard with a wired remote control. With two buttons, the display stand can gently be raised and lowered. Controlled movements protect the sensitive touch screen displays.
H-mobile stand
Our white H chassis has 4 smooth castors, two of which are lockable to fix the tv cart & mobile monitor stand in place. Due to the special H shape even wheelchair users can approach very close to the display.
Double-castor mobile stand
The smooth-running wheels on our chassis make it easy to move the mobile monitor stand and flat screen tv cart even with heavy displays. The castors have a diameter of 50 mm.
Display mount XL for 70" to 120" displays for 2 pylon columns
This XL frame accommodates 70 to 120 inch monitors. The sturdy construction consists of 2 mm powder coated steel. Power strips can be mounted on the frame and, thanks to the cable management, no cables hang down on the system.
Description
Designed specifically for use with interactive touch screen displays, this motorized mobile tv cart features an extra wide display bracket. The mobile solution comes standard with two 3-tier columns which offer 70 cm of height adjustment. Large handles on each side of the display are optionally available for the mobile stand to increase mobility and to help protect the display in transport.
Product ships flat-packed. Cartons are courier shippable.
Specifications
| Mounting | |
|---|---|
| Minimum screen size | 177.8 cm (70") |
| Maximum weight capacity | 250 kg |
| Number of displays supported | 1 |
| Mounting type | Floor |
| Minimum VESA mount | 400 x 200 mm |
| Maximum VESA mount | 1200 x 600 mm |
| Maximum screen size | 3.05 m (120") |
| Ergonomics | |
| Lockable wheels | Yes |
| Height adjustment | Yes |
| Height adjustment range | 1260 - 1960 mm |
| Telescopic | Yes |
| Number of wheels | 4 wheel(s) |
| Minimum distance to floor | 94 cm |
| Maximum distance to floor | 164 cm |
| Lift | 70 cm |
| Distance to the wall (max) | 20 cm |
| Base type | H-shaped |
| Remotely operated | Yes |
| Design | |
| Base type | H-shaped |
| Type | Portable floor stand |
| Housing material | Aluminium |
| Product colour | Black, White |
| Power | |
| Remotely operated | Yes |
| Weight & dimensions | |
| Height (min) | 126 cm |
| Width | 1285 mm |
| Depth | 720 mm |
| Weight | 7.5 kg |
| Height (max) | 196 cm |
| Package 3 weight | 24.2 kg |
| Package 3 dimensions (W x D x H) | 1140 x 780 x 150 mm |
| Package 2 weight | 26 kg |
| Package 2 dimensions (W x D x H) | 1130 x 210 x 745 mm |
| Package width | 760 mm |
| Package depth | 270 mm |
| Package height | 220 mm |
| Package weight | 24 kg |
| Packaging data | |
| Package 3 weight | 24.2 kg |
| Package 3 dimensions (W x D x H) | 1140 x 780 x 150 mm |
| Package 2 weight | 26 kg |
| Package 2 dimensions (W x D x H) | 1130 x 210 x 745 mm |
| Package 4 dimensions (WxDxH) | 760 x 270 x 220 mm |
| Package 4 weight | 24 kg |
| Package width | 760 mm |
| Package depth | 270 mm |
| Package height | 220 mm |
| Package weight | 24 kg |
| Package 1 weight | 18 kg |
| Package 1 dimensions (WxDxH) | 1295 x 450 x 160 mm |
| Technical details | |
| Telescopic | Yes |
| Remotely operated | Yes |
| Number of wheels | 4 wheel(s) |
| Number of displays supported | 1 |
| Mounting type | Floor |
| Minimum distance to floor | 94 cm |
| Maximum distance to floor | 164 cm |
| Lift | 70 cm |
| Distance to the wall (max) | 20 cm |
