Blustream RX70CS AV receiver stereo Black
- Brand: BLUSTREAM
- Category:
- SKU: RX70CS
- EAN:
RJ45, HDMI, S/PDIF, RS-232, IR, HDCP, PoC, 140 x 84 x 18 mm
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
HDBaseT™ CSC Receiver supporting HDMI 2.0 4K 60Hz 4:4:4 & up to 40m (1080p up to 70m), ARC, Bi-directional IR & RS-232, Audio Breakout, Bi-directional PoC, HDCP 2.2 |
RX70CS |
Description
Our RX70CS HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) HDCP 2.2 HDBaseT™ ARC Receiver offers market leading features and outstanding value utilising CSC technology.
The product extends HDMI, Bi-directional IR & RS-232 and is powered by the matrix up to lengths of 70m at 1080p (4K 18Gbps to 40m).
The Receiver features ARC support when used with compatible Blustream hardware and simultaneous analogue stereo and Optical Toslink audio breakout.
- Supports bi-directional PoC to power RX70CS from compatible Blustream HDBaseT™ transmitter / matrix products or provide power to HDBaseT™ transmitter when RX70CS is powered with local power supply
- HDCP 2.2 support
- Recommended receiver for the Blustream AMF42AU, C66CS and C88CS matrix products
The product extends HDMI, Bi-directional IR & RS-232 and is powered by the matrix up to lengths of 70m at 1080p (4K 18Gbps to 40m).
The Receiver features ARC support when used with compatible Blustream hardware and simultaneous analogue stereo and Optical Toslink audio breakout.
- Supports bi-directional PoC to power RX70CS from compatible Blustream HDBaseT™ transmitter / matrix products or provide power to HDBaseT™ transmitter when RX70CS is powered with local power supply
- HDCP 2.2 support
- Recommended receiver for the Blustream AMF42AU, C66CS and C88CS matrix products
Specifications
| Audio | |
|---|---|
| Receiver type | stereo |
| Inputs | |
| Audio (L/R) in | 1 |
| Remote (IR) input | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Outputs | |
| Number of HDMI outputs | 1 |
| Audio (L/R) out | 1 |
| Remote (IR) output | 1 |
| Ports & interfaces | |
| Speakers connectivity type | 3.5mm |
| RS-232 ports | 1 |
| Video | |
| Supported graphics resolutions | 640 x 512, 640 x 640, 640 x 160, 640 x 352, 640 x 360, 640 x 400, 640 x 480 (VGA), 640 x 544, 640 x 576, 640 x 960, 704 x 480, 704 x 576, 720 x 350, 720 x 400, 720 x 480, 720 x 576, 720 x 720, 752 x 582, 768 x 432, 768 x 448, 768 x 494, 768 x 576, 800 x 448, 800 x 450, 800 x 480 (WVGA), 800 x 500, 800 x 592, 800 x 600 (SVGA), 832 x 624, 832 x 642, 848 x 480, 854 x 480 (WVGA), 900 x 720, 960 x 960, 960 x 480, 960 x 540, 960 x 576, 960 x 720, 1024 x 576 (WSVGA), 1024 x 600, 1024 x 640, 1024 x 768 (XGA), 1024 x 800, 1032 x 452, 1056 x 144, 1080 x 1080, 1152 x 864 (XGA+), 1152 x 870, 1200 x 1600, 1200 x 1920, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 768, 1280 x 800 (WXGA), 1280 x 800, 1280 x 960, 1280 x 1280, 1284 x 560, 1296 x 732, 1360 x 768 (WXGA), 1366 x 480, 1366 x 760, 1366 x 768, 1366 x 768, 1368 x 768, 1376 x 768, 1400 x 1050 (SXGA+), 1400 x 1080, 1400 x 900, 1440 x 1050, 1440 x 1080, 1440 x 234, 1440 x 900 (WXGA+), 1440 x 900, 1440 x 912, 1536 X 6144, 1536 x 2048, 1536 x 1536, 1600 x 1200 (UXGA), 1600 x 1280, 1600 x 600, 1600 x 900, 1600 x 904, 1680 x 1050 (WSXGA+), 1680 x 1056, 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 502 |
| Supported video modes | 480i, 1080p |
| Technical details | |
| Audio Return Channel (ARC) | Yes |
| Audio decoders | DTS-HD Master Audio, Dolby Atmos, Dolby TrueHD |
| Product colour | Black |
| Power | |
| AC input voltage | 12 V |
| Weight & dimensions | |
| Width | 140 mm |
| Depth | 98 mm |
| Height | 18 mm |
| Weight | 500 g |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 55 °C |
| Storage temperature (T-T) | -25 - 70 °C |
