Blustream PRO48HBT70CS video distributor HDMI
- Brand: BLUSTREAM
- Category:
- SKU: PRO48HBT70CS
- EAN:
HDMI, RJ-45, IR, DB-9, PoC, 2U, 440 x 87 x 282 mm
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Custom Pro 4x8 HDBaseT™ CSC Matrix - 4K 60Hz 4:4:4 to 40m (1080p up to 70m) - supports 4K HDR, IP / RS-232 Control, PoC, 2-Way IR, Audio Breakout with line level volume control, HDCP 2.2 |
PRO48HBT70CS |
Description
Our Custom Pro 4x8 HDBaseT™ CSC Matrix offers unprecedented 4K HDR performance for the custom installation market.
The PRO48HBT70CS is a HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 Matrix utilising CSC technology to deliver HDMI, Bi-directional IR, PoC up to lengths of 70m over a single CAT cable (4K with HDR up to 40m), with independent down-scaling of 4K video inputs on the CSC HDBaseT™ outputs to allow displays only capable of supporting lower video resolutions to receive 4K video while still showing maximum original 4K UHD resolution on the higher-definition displays.
The Matrix also provides advanced features including audio breakout and a web browser interface module for control and configuration of the matrix.
Specifications
| Ports & interfaces | |
|---|---|
| Connector gender | Female |
| Input type | HDMI |
| Number of outputs | 8 outputs |
| Technical details | |
| Connector gender | Female |
| Input type | HDMI |
| Number of outputs | 8 outputs |
| Product colour | Black |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 252 mm |
| Height | 87 mm |
| Package weight | 5 kg |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Power supply | |
| AC adapter input voltage | 24 V |
| AC adapter input current | 8 A |
