| Projector |
|---|
| Number of colours | 1.07 billion colours |
| Projector native resolution | WUXGA (1920x1200) |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 4:3, 16:9 |
| Projection distance | 1 - 9.1 m |
| Contrast ratio (typical) | 20000:1 |
| Zoom capability | Yes |
| Projector brightness (economic mode) | 4400 ANSI lumens |
| Vertical synchronization (min) | 24 kHz |
| Vertical synchronization (max) | 120 kHz |
| Uniformity | 85% |
| Keystone correction, vertical | +/- 30° |
| Keystone correction, horizontal | +/- 30° |
| Horizontal synchronization (min) | 15 kHz |
| Horizontal synchronization (max) | 100 kHz |
| Projection technology | DLP |
| Projector brightness | 5500 ANSI lumens |
| Lamps |
|---|
| Lamp type | UHP |
| Lamp power | 365 W |
| Light source type | Lamp |
| Service life of light source | 3000 h |
| Service life of light source (economic mode) | 4000 h |
| Light source |
|---|
| Lamp type | UHP |
| Lamp power | 365 W |
| Light source type | Lamp |
| Service life of light source | 3000 h |
| Service life of light source (economic mode) | 4000 h |
| Lens system |
|---|
| Zoom capability | Yes |
| Focus | Auto/Manual |
| Focal length range | 2.50~3.26 mm |
| Vertical lens shift range | 44 - 57% |
| Throw ratio | 1.41~2.24:1 |
| Video |
|---|
| Full HD | Yes |
| 3D | Yes |
| Audio |
|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 10 W |
| Ports & interfaces |
|---|
| Mobile High-Definition Link (MHL) | Yes |
| HDMI connector type | Full-size |
| HDBaseT port | Yes |
| USB 2.0 Type-B ports quantity | 1 |
| PC in (D-Sub) | Yes |
| VGA (D-Sub) ports quantity | 2 |
| HDMI ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 1 |
| Composite video in | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| S-Video inputs quantity | 1 |
| Serial interface type | RS-232 |
| DVI port | Yes |
| Component video (YPbPr/YCbCr) in | 1 |
| Network |
|---|
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet LAN (RJ-45) ports | 1 |
| Sound emission |
|---|
| Noise level | 35 dB |
| Noise level (economic mode) | 30 dB |
| Technical details |
|---|
| PC in (D-Sub) | Yes |
| Product colour | Black |
| HDCP | Yes |
| Lamp power | 365 W |
| Performance |
|---|
| Market positioning | Business |
| HDCP | Yes |
| Noise level | 35 dB |
| Noise level (economic mode) | 30 dB |
| Features |
|---|
| HDCP | Yes |
| Noise level | 35 dB |
| Noise level (economic mode) | 30 dB |
| Multimedia |
|---|
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 10 W |
| Design |
|---|
| Market positioning | Business |
| Product type | Standard throw projector |
| Product colour | Black |
| Display |
|---|
| Built-in display | No |
| Power |
|---|
| Power source | AC |
| Power consumption (typical) | 460 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (economy mode) | 367 W |
| Packaging data |
|---|
| Package width | 556 mm |
| Package depth | 474 mm |
| Package height | 214 mm |
| Package weight | 8.4 kg |
| Supplier features |
|---|
| Harmonized System (HS) code | 85286200 |
| Weight & dimensions |
|---|
| Package width | 556 mm |
| Package depth | 474 mm |
| Package height | 214 mm |
| Weight | 4.5 kg |
| Width | 369 mm |
| Depth | 294 mm |
| Height | 116 mm |
| Package weight | 8.4 kg |
| Packaging content |
|---|
| Cables included | VGA |
| Other features |
|---|
| Power consumption (economy mode) | 367 W |
