ATEN Room Booking System - 10.1" RBS Panel
- Brand: ATEN
- Category:
- SKU: VK430
- EAN: 4710469341588 0672792013393
Room Booking System - 10.1" RBS Panel
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
10.1" ouch Pnel wih Room |
VK430-AT | |||
|
Room Booking - Access Inspector |
ATN-VK430-AT | |||
|
|
Room Booking System - 10.1" Panel |
ATN-VK430 | |||
|
VK430 Room Booking System - 10.1in Panel |
AVATEN291 | |||
|
VK430 - Room manager - wired - Gigabit Ethernet View on InTouch |
11494605 | |||
|
VK430 Room Booking System 10.1 Inch RBS Panel |
ATE0730 | |||
|
VK430-AT |
VK430 | |||
|
Room Booking System - 10.1 Panel |
VK430 | |||
|
VK430 |
ATENVK430 | |||
|
VK430 |
ATENVK430 |
Related Products
-
Category: Matrix Switchers
Description
ATEN VK430 RBS Panel is a 10.1" touch-screen panel used to manage conference rooms, and is centrally configured by ATEN RBS Configurator – centralized management software of RBS Panels while integrating with calendar servers, such as Microsoft Office 365 Calendar – to provide convenient scheduling and availability allocation for all conference rooms in the system. That is, through a few simple taps, authorized personnel can make conference room reservations, extend or release room usage, and check the booking schedules of any conference room directly on the VK430 while enjoying its user-friendly interface. In addition, through ATEN RBS Configurator, administrators can have a centralized view of the availabilities and locations of all conference rooms in real time as well as manage each VK430 connected from afar, elevating meeting room utilization efficiency.
Highlighted features of the VK430 include its Power over Ethernet (PoE) support and two illuminating LED bars. With PoE, VK430 can transmit data while receiving power over a single Ethernet cable, which effectively reduces installation costs and power consumption. The two LED light bars, one on each side, illuminates in user-defined colors to indicate the availability status of the conference room, available, reserved, or occupied, and allow users to know the room’s availability at a glance.
Without compromise on aesthetics, VK430 features a sleek and elegant housing that supports 75*75 mm VESA-compliant mounting options to suit various installation scenarios. VK430 is preinstalled with its standard wall mount kit while providing 3M VHB™ Tape for it to be easily installed onto a hard or glass wall.
The VK430, along with the ATEN RBS Configurator, delivers an enterprise-grade room management solution perfect for all business environments, making meeting room management a breeze while elevating the overall room-booking experience.
Highlighted features of the VK430 include its Power over Ethernet (PoE) support and two illuminating LED bars. With PoE, VK430 can transmit data while receiving power over a single Ethernet cable, which effectively reduces installation costs and power consumption. The two LED light bars, one on each side, illuminates in user-defined colors to indicate the availability status of the conference room, available, reserved, or occupied, and allow users to know the room’s availability at a glance.
Without compromise on aesthetics, VK430 features a sleek and elegant housing that supports 75*75 mm VESA-compliant mounting options to suit various installation scenarios. VK430 is preinstalled with its standard wall mount kit while providing 3M VHB™ Tape for it to be easily installed onto a hard or glass wall.
The VK430, along with the ATEN RBS Configurator, delivers an enterprise-grade room management solution perfect for all business environments, making meeting room management a breeze while elevating the overall room-booking experience.
Specifications
| Display | |
|---|---|
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1280 x 800 pixels |
| Aspect ratio | 16:10 |
| Touchscreen technology | Capacitive |
| Design | |
| Housing material | Plastic |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 55 °C |
| Audio | |
| Built-in speaker(s) | No |
| Network | |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ports & interfaces | |
| RJ-45 ports quantity | 1 |
| USB 2.0 Type-A ports quantity | 1 |
| Power | |
| Power source type | DC, PoE |
| Input voltage | 12 V |
| Weight & dimensions | |
| Width | 177.8 mm |
| Depth | 263 mm |
| Height | 37.2 mm |
| Weight | 900 g |
| Packaging data | |
| Package width | 360 mm |
| Package depth | 234 mm |
| Package height | 52 mm |
| Package weight | 1.24 kg |
| Packaging content | |
| Quick start guide | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Technical details | |
| Package volume | 4530.7 cm³ |
| Master (outer) case volume | 28033.68 cm³ |
| Master (outer) case width | 288 mm |
| Master (outer) case length | 370 mm |
| Master (outer) case height | 263 mm |
| Master (outer) case gross weight | 6.7 kg |
| Features | |
| Built-in speaker(s) | No |
| Logistics data | |
| Master (outer) case width | 288 mm |
| Master (outer) case length | 370 mm |
| Master (outer) case height | 263 mm |
| Master (outer) case gross weight | 6.7 kg |
