APC Symmetra PX 32kW Scalable to 96kW 400V with Modular Power Distribution
- Brand: APC
- Category:
- SKU: SY32K96H-PD
- EAN:
Symmetra PX 32kW Scalable to 96kW 400V with Modular Power Distribution
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Symmetra PX 32kW - 96kW 400V MPD |
000000000000107168 | |||
|
SYMMETRA PX 32KW SCALABLE View on Xvantage |
2707735 | |||
|
Please contact sales for freight costs View on InTouch |
6756131 | |||
|
SYMMETRA PX 32-96KW 400V POWER DIST View on Webshop |
SY32K96H-PD | |||
| Ingram Micro CS |
SYMMETRA PX 32KW SCALABLE |
2707735 |
| Alternative Suppliers | |||||
|---|---|---|---|---|---|
|
SYMMETRA PX 32-96KW 400V POWER DIST |
CLSY32K96H-PD | |||
Related Products
-
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions
Description
A high-efficiency 3-phase UPS with integrated modular distribution that can be right-sized to your data center power requirements. With scalable power, distribution and run-time, this UPS grows with your data center up to 96 kW/96 kVA. Suitable for small to medium data centers or individual zones of large data centers.
Specifications
| Power | |
|---|---|
| Output power | 96000 W |
| Input operation voltage (min) | 340 V |
| Input operation voltage (max) | 477 V |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Maximum current | 59 A |
| Efficiency | 95% |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Output power capacity | 96 kVA |
| Battery | |
| Battery type | VRLA |
| Battery recharge time | 3.50 h |
| Hot-swap battery | Yes |
| Performance | |
| Number of phases | 3 |
| EMI/RFI noise filtering | Yes |
| Power protection features | Over current, Overload |
| Noise level | 61 dB |
| Audible alarm(s) | Yes |
| Features | |
| Output power | 96000 W |
| Input operation voltage (min) | 340 V |
| Input operation voltage (max) | 477 V |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Maximum current | 59 A |
| Efficiency | 95% |
| EMI/RFI noise filtering | Yes |
| Emergency Power Off (EPO) | Yes |
| Power protection features | Over current, Overload |
| Output voltage Total Harmonic Distortion (THD) | 2% |
| Noise level | 61 dB |
| Audible alarm(s) | Yes |
| Output power capacity | 96 kVA |
| Input frequency | 50/60 Hz |
| Number of phases | 3 |
| Ports & interfaces | |
| AC outlet types | Hard Wire 5-wire (3P + N + E) |
| Design | |
| Product colour | Black |
| Certification | EN 50091-1,EN/IEC 62040-3,EN/IEC 62040-1-1,FCC Part 15 Class A,VFI-SS-111 |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 999.9 m |
| Non-operating altitude | 0 - 15000 m |
| Technical details | |
| Harmonized System (HS) code | 85078000 |
| Packaging data | |
| Package dimensions (WxDxH) | 1696 x 1210 x 2140 mm |
| Package weight | 1963 kg |
| Certificates | |
| Certification | EN 50091-1,EN/IEC 62040-3,EN/IEC 62040-1-1,FCC Part 15 Class A,VFI-SS-111 |
| Weight & dimensions | |
| Weight | 1814 kg |
| Width | 1200 mm |
| Package weight | 1963 kg |
| Height | 1991 mm |
| Depth | 1070 mm |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Number of phases | 3 |
| Interface | 2 x SmartSlot |
| Battery type | VRLA |
| Package dimensions (WxDxH) | 1696 x 1210 x 2140 mm |
| Overload protection | Yes |
| Output voltage note | 380: 400 / 415 V 3 Ph |
| Nominal output voltage | 400 V |
| Nominal input voltage | 400 V |
