Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Symmetra LX 16kVA - 16kVA Tower |
000000000000106785 | |||
|
SYMMETRA LX 8KVA TO 16KVA View on Xvantage |
2702315 | |||
|
SYMMETRA LX 16KVA SCALABLE TO 16KVA N+1 TOWER, 220/230/240V OR 380/400/415V |
SYA16K16I | |||
|
Please contact sales for freight costs View on InTouch |
925482 | |||
|
SYMMETRA LX 16KVA TOWER View on Webshop |
SYA16K16I | |||
| Ingram Micro CS |
SYMMETRA LX 8KVA TO 16KVA |
2702315 |
| Alternative Suppliers | |||||
|---|---|---|---|---|---|
|
SYMMETRA LX 16KVA TOWER |
CLSYA16K16I | |||
Description
High performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks.
Specifications
| Power | |
|---|---|
| Output power | 11200 W |
| Emergency Power Off (EPO) | Yes |
| Output power capacity | 16 kVA |
| Battery | |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
| Typical backup time at half load | 20.3 min |
| Typical backup time at full load | 7.5 min |
| Replacement battery cartridge | SYBT5 |
| Features | |
| Output power | 11200 W |
| Emergency Power Off (EPO) | Yes |
| Output power capacity | 16 kVA |
| Ports & interfaces | |
| AC outlet types | Hardwire |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Technical details | |
| Harmonized System (HS) code | 85078000 |
| Total carbon footprint (kg of CO2e) | 53926.34 |
| Weight & dimensions | |
| Weight | 308 kg |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Total carbon footprint (kg of CO2e) | 53926.34 |
| Other features | |
| Interface | DB-9 RS-232, Smart-Slot |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
| Output connections | (1) Hard Wire 3-wire (H N + G) |
| Input connection type | Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G) |
| Dimensions (WxDxH) | 480 x 730 x 940 mm |
| Output voltage note | Configurable for 220: 230 or 240 nominal output voltage |
| Nominal output voltage | 230 V |
| I/O ports | Available Smart Slot Interface Quantity - 1 Pre-Installed SmartSlot Cards - AP9619 |
