Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Symmetra LX 16kVA - 16kVA Tower |
000000000000106785 | |||
|
SYMMETRA LX 8KVA TO 16KVA View on Xvantage |
2702315 | |||
|
SYMMETRA LX 16KVA SCALABLE TO 16KVA N+1 TOWER, 220/230/240V OR 380/400/415V |
SYA16K16I | |||
|
Please contact sales for freight costs View on InTouch |
925482 | |||
|
SYMMETRA LX 16KVA TOWER View on Webshop |
SYA16K16I | |||
| Ingram Micro CS |
SYMMETRA LX 8KVA TO 16KVA |
2702315 |
| Alternative Suppliers | |||||
|---|---|---|---|---|---|
|
SYMMETRA LX 16KVA TOWER |
CLSYA16K16I | |||
Reasons To Buy
Allows quick and easy installation and maintenance of the UPS.
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Description
"High performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks."
Specifications
| Power | |
|---|---|
| Output power | 11200 W |
| Emergency Power Off (EPO) | Yes |
| Output power capacity | 16 kVA |
| Battery | |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
| Typical backup time at half load | 20.3 min |
| Typical backup time at full load | 7.5 min |
| Replacement battery cartridge | SYBT5 |
| Features | |
| Output power | 11200 W |
| Emergency Power Off (EPO) | Yes |
| Output power capacity | 16 kVA |
| Ports & interfaces | |
| AC outlet types | Hardwire |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Technical details | |
| Harmonized System (HS) code | 85078000 |
| Total carbon footprint (kg of CO2e) | 53926.34 |
| Weight & dimensions | |
| Weight | 308 kg |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Total carbon footprint (kg of CO2e) | 53926.34 |
| Other features | |
| Interface | DB-9 RS-232, Smart-Slot |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof |
| Output connections | (1) Hard Wire 3-wire (H N + G) |
| Input connection type | Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G) |
| Dimensions (WxDxH) | 480 x 730 x 940 mm |
| Output voltage note | Configurable for 220: 230 or 240 nominal output voltage |
| Nominal output voltage | 230 V |
| I/O ports | Available Smart Slot Interface Quantity - 1 Pre-Installed SmartSlot Cards - AP9619 |
